Modular system overview
Baozhen-Tank stormwater modules provide an efficient and versatile underground stormwater storage system to assist with stormwater detention, infiltration and rainwater harvesting applications. With 95% void space, this system will allow you to reduce your underground stormwater storage system footprint to resolve utility conflicts or free up space for a future expansion. Due to the patented design of the system, it is one of the most efficient systems on the market and is a cost-effective alternative to stormwater basins and other underground systems.
Nine different module configurations provide module options from 3” to over 20” tall. In addition, BZ-Tank delivers support for HS-20 and HS-25 traffic loads, with cover depths ranging from 6” to over 78”.critical component of any BZ-Tank design is the geotextile fabrics used to wrap the tanks. The fabrics used can change the application. For instance, BZ-Tank can be designed to discharge the stormwater runoff into a drainage system,release the stormwater back into the ground, or contain the water for future use.
Onsite Stormwater Management.
• Environmentally friendly made from selected 100% Recycled Polypropylene.
• Recharges Groundwater Table through the principle of infiltration.
• Mitigation of downstream flooding.
• Site space utilization and minimum site disruption.
• Economical and Low system and reduces liability issues.
• Modular Structure for design flexibility.
• Heavy load-carrying capacity.
• Supplied in Kit form for ease in transportation.
• High void surface ratio for quicker infiltration.
• Lightweight hence no heavy machinery or skilled labor required.
We are receive more than 200 projects every year, with the number of projects ranging from 300m3 to 10,000m3. So far, our products have been recognized by customers from the United States, Europe, Middle East and other countries.We also do our best to provide customers with high quality, competitive products.
We are a professional manufacturer and we will optimize your supply chain.
